Solar stringing, done
Branch strings your panels, routes homeruns, and exports circuit lengths for any sized project in under 3 minutes. Built in AutoCAD for commercial rooftop, ground mount, and SolarEdge project design.
How Branch works
Seamlessly integrated into your existing AutoCAD workflow.
Install the Plugin
Download and install Branch directly into AutoCAD. Works with AutoCAD 2018–2026 on Windows.
Configure Your Project
Select your project type, jurisdiction, and design parameters. Branch handles the rest.
Automate & Design
Generate string layouts, route homeruns, and export circuit lengths with a few commands.
Explore workflow detailsWhat Branch does
Everything you need to generate accurate stringing designs in AutoCAD.
Automatic Stringing
Optimized string layouts for any rooftop or ground mount. Handles SolarEdge optimizers, Enphase microinverters, and traditional string inverters.
Homerun Routing
Automatic routing from strings to inverters and combiner boxes. Adjust paths afterward with move, angle, and insert tools.
Circuit Length Export
Accurate wire lengths for every circuit. Export to schedules without manual measuring.
SolarEdge Import
Import SolarEdge Designer PDFs directly into AutoCAD. Clean panel positions, string assignments, and optimizer placements.
MPPT Balancing
See balance status across all inverters at a glance. Smart swap suggestions fix mismatches between MPPTs with one click.
CD-Ready Output
Proper layers, formatting, and annotation ready for construction documents.
Why engineers love Branch
Stop counting modules and measuring wire runs by hand. Let Branch handle the tedious parts.
- No more manual string counting
- Accurate circuit lengths without measuring
- Works with your existing panel layouts
- SolarEdge, Enphase, and string inverters supported
- Import from Helioscope, Aurora, or SolarEdge Designer
- In and out — no complex setup required
- Counting panels for strings
- Hand-typing every custom tag
- Drawing homerun polylines
- Extracting line-lengths to Excel
- Doing it all again when plans change
